Wagon Drill (SKE WD-100)

Heavy Duty Design: Constructed with heavy-duty ISMC members, it is capable of withstanding drilling blast holes in horizontal, vertical, and angular positions.
The WD-100 is equipped with four 4.5 HP air motors, gearboxes, and a 6 HP rotation gearbox, delivering enhanced productivity. It features a heavy-duty 14″ feed chain for deep drilling and offers rear-wheel drive as an optional feature.
Portability: WD-100 is compact and easy to transport with the compressor on a mining site.
DTH Drilling: WD-100 is designed to operate with a powerful DTH hammer.
Air Driven Motor: WD-100 features a newly designed, high-performance 4.5 HP air-driven motor. All four motors are identical and fully interchangeable, ensuring cost-effective maintenance and operation.
Maintenance: The machine is easy to repair and offers a budget-friendly cost of ownership.
Productivity: WD-100 can drill up to 50 feet/hr.
