We manufacture a wide range of drilling rigs including waterwell DTH rigs, piling rigs, mining rigs (wagon drill & crawler), and tractor-mounted drills.
Yes, we supply high-quality spare parts and offer comprehensive maintenance and service support for our rigs and compressors.
Absolutely! Our rigs and accessories are engineered for high penetration and durability to perform efficiently in varied rock formations and terrains.
Yes, while we have a strong domestic presence, we are expanding globally and welcome inquiries for international projects.
SKE- DTH-100 Technical Data | |
---|---|
Application | Water Well Drilling |
Feed System | Pull back: 260KN |
Pull down: 127KN | |
Pull Up Speed: 36m/min | |
Pull Down Speed: 75m/min | |
Drill Feed: 1.5m/min | |
Tower | Length: 9m |
Width: 520mm | |
Depth: 420mm |
ROTARY HEAD | |
---|---|
Torque | Low Speed: 8,000 ft-lbs (10.8 KN-m) @105 rpm High Speed: 5,400 ft-lbs (7.3 KN-m) @160 rpm |
Rotation Speed | 0 to 160 rpm |
Spindle | 120 mm Spindle OD |
Head Travel | 23 ft (7.05 m) |
BREAK OUT WRENCH | |
Clamping Range | 3-1/2 inch (90mm) to 5 inch (127mm) |
Torque | 16,000 lb-ft (21.7 KN-m) |
ROD HANDLING | |
Manual Rod Handler (ARH) | Rod Size: 4-1/2 inch (114.3 mm) |
Rod Box Capacity | 6 Rods @19 ft (6m) |
DHD LUBRICATOR | |
Flow | 1 to 1.5 ltr/hr |
Control | Flow Control STEPLESS Position Selector |
Capacity | 15 L |
CHASSIS | |
Ashok Leyland 2820 or similar variant as Per Customer Request | |
Hydraulic System is Powered by Truck Engine Through Specially Designed PTO | |
LEVELLING JACK | |
Drill End Jack Bore | 100mm Stroke 850mm |
Non Drill End Bore | 100mm Stroke 850mm |
HYDRAULICS | |
Hydraulic Tank Capacity | 159 gallons (600L) |
Hydraulic Filtration | 10 micron |
Main Pump | 151 cc @2,500 psi (180 bar) |
Rotation Motor | 400 cc @2,500 psi (173 bar) |
Slow Feed pump | 7.5 cc @2,500 psi (173 bar) |
Jack Levelling Pump | 18.2 cc @2,500 psi (173 bar) |
WATER INJECTION PUMP | |
Flow 56 lpm |
